Comprehensive HVAC Software in AViCAD

AViCAD’s Ducting Software is a comprehensive collection of utilities for drawing 2-D & 3-D HVAC Ducting. Duct shape options include rectangular, round and flat oval.

Software Features include: auto-BOM, auto-labeling, flat sheet development.

HVAC Duct fittings included: Duct bends, transitions, tees & wyes, offsets, branches, dampers, diffusers, flexible duct, grills, build-in & customer defined symbols and many accessories…

Ducting Software Draws These Shapes:

  • Rectangular
  • Round
  • Flat oval ducting

Lets you generate complex HVAC ducting layouts with surprising ease. This ducting software adds insulation as required and bends design is fully customizable.

HVAC Software Main Features:

  • Rectangular, Round & Flat Oval Duct. w/ or w/o insulation
  • The Ducts can drawn with Flanges and Collars.
  • Build-in and customizable symbols, duct labels, elevation
  • Fully customizable and several configurations can be saved.
  • Duct data listing for easy identification of parts
  • Duct, bends & tees – Cut sheet development.
  • Full Layers Control
  • Duct identification labels & Elevation labels
  • Available with 2-D & 3-D (solid) capabilities.
  • Auto-BOM with sheet material take-off.
  • Duct Equivalent Size calculator
  • Metric and English units supported
  • Vast range of ducting shapes:
  • Duct Transforms & Transitions
  • Duct Tees & Wyes
  • Duct Branches
  • Duct Diffusers
  • Duct Offsets

Ducting Software also includes a large range of ducting accessories including:

  • Flexible duct
  • Conical fittings
  • Trminal units
  • Heating units
  • Registers
  • Return air grills many more…
